The ACM Series Fine Powder Grinding System is composed of an air classification mill, a cyclone separator, a rotary or vibrating sieve, an ultra-fine powder collection box, and a high-pressure fan. It offers functionalities such as high-speed pulverization, air classification, cyclone separation, sieving, and ultra-fine powder collection. Adjusting operational parameters allows for achieving the desired particle size distribution. The ACM Series Fine Powder Grinding System is also suitable for grinding pigments, calcium powder, carbon powder, pharmaceuticals, and food products.
Particle size distribution is concentrated, stable, and adjustable.
High recovery rate (>98%).
Low temperature rise of the mill and low temperature of the powder.
Double butterfly valve or off-fan discharge.
Leaf valve or screw feeding.
Low noise,ease of cleaning and maintenance.
The dual classification system greatly improves the concentration of particle size.
Customizable internal circulating milling system.
Human-machine interaction, PLC touch screen control, easy to operate.
Process parameter and formula management, remote monitoring.
Perfect security protection system.
Before the main mill or the rotating screen, a feeding device for additives can be installed.
Designed in accordance with the GB (National Standard) and EN (European Standard) standards for "Calculation, Design and Testing of Impact Resistant Pressure Vessels" and "Dust Explosion Pressure Relief".
| Model | Max Output | Main Mill Motor | Main Mill Speed MAX | Graded Motor | Graded Speed | Fan Power | Air Volume |
| ACM-02 | 30 | 2.2 | 13955 | 0.55 | 3000 | 3 | 330 |
| ACM-07 | 120 | 5.5 | 10350 | 1.1 | 3000 | 7.5 | 510 |
| ACM-10 | 240 | 7.5 | 7437 | 1.5 | 3000 | 11 | 900 |
| ACM-15 | 300 | 11 | 7437 | 2.2 | 3000 | 15 | 1350 |
| ACM-20 | 400 | 15 | 6273 | 3 | 3000 | 22 | 1800 |
| ACM-25 | 500 | 18.5 | 6273 | 4 | 3000 | 30 | 2250 |
| ACM-30 | 600 | 22 | 5028 | 5.5 | 3000 | 37 | 2700 |
| ACM-40 | 800 | 30 | 5028 | 5.5 | 3000 | 45 | 3600 |
| ACM-50 | 1000 | 37 | 3469 | 7.5 | 3000 | 55 | 4500 |
| ACM-60 | 1200 | 45 | 3469 | 7.5 | 2650 | 75 | 5400 |
| ACM-75 | 1500 | 55 | 2657 | 11 | 2400 | 90 | 6750 |
| ACM-100 | 2000 | 75 | 2657 | 11 | 2400 | 110 | 9000 |
Automatic Weighing System
Automated control, precise weighing
Automated carton recognition, fills in pre-set amount for the carton size
Vacuum system recycles escaping powder, minimising contamination
Only 1 operator needed, lowered production cost, high production efficiency
Lengths: 2m, 2.5m, 3m for your practical needs
